Vial Adapter, also known as vial connector, withdrawal spike, or injection spike for liquid transfer, is a drug preparation and delivery tool used in healthcare and pharmaceutical industries. It allows liquid to be drawn from a vial and transferred to a syringe without using a needle, reducing needlestick injury risk and contamination during drug preparation.

Key Features

[Safety]: Designed to provide dual safety, protecting healthcare workers from needlestick injuries and reducing the risk of drug contamination.

[Sealing]: Ensures the vial's sealing performance, preventing liquid leakage or external contamination.

[Flexibility]: Compatible with a variety of vial sizes and syringes (ISO 80369-7 luer-lock and luer-slip), with a wide range of applicability.

Model & Specification Table

Chi Feng offers vial adapters for 13mm and 20mm standard vials, plus universal, mini, filter and integrated connector versions.

Vial-to-vial adapters also available. Custom colors and materials on request, contact us for the full range.

0.2-micron Filter Options

Our filter models serve two distinct needs:

Vented (pressure-balancing): the 0.2-micron membrane lets air pass while blocking bacteria and particles, preventing vacuum lock when drawing and spray-back when injecting. Ideal for compounding and multi-dose vial use.

Particle filtration: filters glass shards, rubber stopper coring and sediment, ideal when drawing from ampoules, older vials, or repeatedly punctured multi-dose vials.

Applications

Vial Adapter is widely used in the following areas:

• Hospitals and clinical settings: healthcare workers extract drugs from vials and deliver them to patients, the adapter makes the process safer and more convenient.
• Pharmaceutical industry: drug sample preparation, quality control tests and production, maintaining the purity and stability of drugs.
• Research laboratories: extracting samples from vials for analysis and testing.
• Cosmetic use: transmission and short-term storage of hyaluronic acid, convenient for aliquoting and use; we have a Korean partner for hyaluronic applications.
• Veterinary and animal health: multi-dose vaccine and antibiotic vial extraction for veterinary clinics and distributors.

How It Works

1. Connect your syringe to the luer port (ISO 80369-7, fits luer-lock and luer-slip).
2. Disinfect the vial stopper with an alcohol swab.
3. Attach the adapter onto the vial (for the T-Mix Hub system: white adapter on the diluent vial, purple adapter on the powder vial).
4. Position the vial above the syringe so gravity assists the flow, minimizing air bubbles.
5. Draw the liquid and proceed; no needle was used at any step.

Advantages

[Improved safety]: Prevents needlestick injuries during drug extraction, improving workplace safety.

[Drug protection]: Protects drugs in the vial from external contamination, ensuring purity and efficacy.

[Accurate dose control]: Allows accurate control of drug dosage, ensuring patients receive the correct treatment.

Learn More in Our Knowledge Hub

Vial Adapter Series, Enhancing Safety and Convenience in Medication Preparation
Vial Adapter, High-Quality Vial Access Solutions (specifications, sterilization, comparison, FAQ)

FAQ

What sterilization methods are available?
EtO (ethylene oxide) and Gamma sterilization are available. The method can be specified per your requirement, confirm your preference when requesting a quote.

What is the difference between the 13mm and 20mm vial adapters?
The 13mm adapter (18A196) fits 13mm vial necks; the 20mm adapter (18A195) fits 20mm vial necks. We also offer universal (13B002) and mini (18C034) versions with 0.2-micron filter.

Is the vial adapter really needle-free?
Yes. The adapter pierces the stopper mechanically, no needle is used to draw or mix, eliminating needle-stick injury risk during transfer.

Which syringes are compatible?
The luer port complies with ISO 80369-7 and fits both luer-lock and luer-slip syringes.

Do you offer a 0.2-micron filter version?
Yes, 13B002 (universal), 18C034 (mini), and 21C009 (QuikLock with filter). The 0.2-micron membrane balances vial pressure and blocks bacteria and particles.

Is each adapter individually sterile-packaged?
The finished packaged sterile version is individually packaged, sterilized in ISO 13485:2016 validated cleanrooms.

Can you customize the label with our brand?
Yes. As an OEM/ODM manufacturer we offer custom labeling, colors, materials and packaging for private-label programs.

What certifications do you hold?
BSI ISO 13485:2016 manufacturing in certified cleanrooms; connectors meet ISO 80369-7 and ISO 10993-1 biocompatibility. The T-Vial Adapter and QuikLock systems carry global patents.

What is the minimum order quantity?
MOQ depends on the model and packaging format. Contact us with your target quantity and destination for a formal quotation.

How do I use the vial adapter?
Attach the adapter to the vial stopper, connect your syringe to the luer port, and draw. Keep the vial above the syringe so gravity assists the flow and minimizes air bubbles.

Let Our Team. Be Your Team.

OEM/ODM services: custom labeling, colors, materials and packaging for your private label, from 13mm to 20mm, filter or non-filter, standard or QuikLock-integrated. Backed by ISO 13485 cleanroom manufacturing and global patents.

Request Samples & MOQ

Chi Feng Co., Ltd. - Established in Taiwan since 1988 | Medical component manufacturer | BSI ISO 13485:2016 certified cleanrooms
Sales: Kevin Tsai - kevintsai@e-elect.com.tw | Pei Tsai - pei@e-elect.com.tw

Vial Adapter: A Must-have Tool in Healthcare and Pharmaceutical Industries

Vial Adapter, also known as vial connector, withdrawal spikes, injection spikes for liquid transfer which is a drug preparation and delivery tool used in healthcare and pharmaceutical industries. It has the following features and working principles:

• [Safety]: Vial Adapter is designed to provide dual safety, protecting healthcare workers from needlestick injuries and reducing the risk of drug contamination.
• [Sealing]: It ensures the vial's sealing performance, preventing liquid leakage or external contamination.
• [Flexibility]: Vial Adapter is typically compatible with a variety of different types of vials and syringes, with a wide range of applicability.

Vial Adapter is widely used in the following areas:

• [Hospitals and clinical settings]: In hospitals and clinical settings, healthcare workers often need to extract drugs from vials and deliver them to patients. Vial Adapter makes the process more safe and convenient.
• [Pharmaceutical industry]: Pharmaceutical companies use Vial Adapter to prepare drug samples, conduct quality control tests, and produce drugs. This helps to maintain the purity and stability of drugs.
• [Research laboratories]: Researchers use Vial Adapter to conduct laboratory research, extracting samples from vials for analysis and testing.
• [Cosmetic use]: The Vial Adapter is versatile, enabling transmission and short-term storage of hyaluronic acid. It's convenient for aliquoting and use, and we have a Korean partner for hyaluronic applications.

The use of Vial Adapter has the following advantages:

• [Improved safety]: Vial Adapter effectively prevents needlestick injuries to healthcare workers during drug extraction, improving workplace safety.
• [Drug protection]: It protects drugs in the vial from external contamination, ensuring the purity and efficacy of drugs.
• [Accurate dose control]: Vial Adapter allows for accurate control of drug dosage, ensuring that patients receive the correct treatment.

In conclusion, Vial Adapter is an important tool in healthcare and pharmaceutical industries. It can improve the efficiency and safety of medical operations, ensuring the safety of patients and the effective use of drugs.
